Fanuc
1PC New FANUC A06B-6088-H330 Servo Drive A06B6088H330 Via DHL One Year Warranty
1PC New FANUC A06B-6088-H330 Servo Drive A06B6088H330 Via DHL One Year Warranty
SKU:A06B-6088-H330
通常価格
$8,616.00 USD
通常価格
セール価格
$8,616.00 USD
単価
あたり
配送料はチェックアウト時に計算されます。
低在庫：残り2個
受取状況を読み込めませんでした
| Delivery: |  |
| Expedited, Freight, and International shipping available. | |
| Payment: |  |
| Visa, MasterCard, American Express, PayPal, more options |
| Model Number | A06B-6088-H330 |
| Type | Servo Amplifier Module |
| Series | FANUC Alpha i (αi) Series |
| Input Voltage | 200-230 VAC |
| Input Frequency | 50/60 Hz |
| Rated Output Current | 80 A (continuous) |
| Peak Output Current | 200 A (maximum) |
| Power Supply Capacity | 26.4 kVA |
| Cooling Method | External Fan Cooling |
| Weight | Approximately 21 kg |
| Dimensions | 380 mm (H) x 380 mm (W) x 180 mm (D) |
| Compatible Motors | FANUC AC Servo Motors (αi series) |
| Communication Interface | FANUC Serial Interface |
| Overload Capacity | 150% for 1 minute |
| Protection Features | Overvoltage, Overcurrent, Overheating, Short Circuit |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 60°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Mounting | Panel Mount |
| Standards Compliance | CE, UL, RoHS |
